PRODUCT SPECIFICATION
Environment friendly
Environment friendly as it does not contain Mercury
Long life
Long life span of 25000 Burning hours
Performance
High performance electronic driver ensures zero maintenance
Wider Spread of Light
With unique curved design & diffused light that spreads 14% wider light as compared to NU Bulb
TECHNICAL SPECIFICATION
POWER FEATURES
| Wattage | 9 W |
| Rated input voltage | 240 V AC |
| Power factor | > 0.9 |
| Frequency | 50 Hz |
| Operating temperature | -10 °C to +35 °C |
BASIC DETAILS
| Suitable for | Corporate Offices, Shopping Malls, Restaurants, Hotel, Modern Gym/Spa, Exhibition Area, Educational Lighting, Indoor Lighting in homes |
| Mounting type | Retrofit |
PERFORMANCE FEATURES
| Lumen (Rated Luminous Flux) | 945 lm |
| Colour rendering index (CRI) | 80 |
| Colour temperature | F6500 |
| Light effect | Cool White |
| Lamp photometric code | 865/15157 |
| Lumen maintenance code | 7 |
| Failure fraction (Fy) | F50 L70 |
| Rated efficacy | 105 lm / W |
FIXTURE DESIGN
| Material | Polycarbonate |
| Body colour | White |
| Fixture shape | Rectangular |
| Diffuser shape | Arc |
| Diffuser transparency | Opal Finish |
| Mounting arrangement | Suitable for B22 lamp holders |
| Driver | Built – In |
SAFETY FEATURES
| Mercury content | No Mercury |
| Voltage withstanding range | 140 V to 270 V |
| IP | IP20 |
WARRANTY \ GUARANTEE
| Warranty | 2 Year |
SALES PACKAGE (S)
| Net contents | 1 Fixture |
DIMENSIONS AND WEIGHT
| Height | 9.0 cm ± 0.2 cm |
| Length | 20.6 cm ± 0.2 cm |
| Width | 3.0 cm ± 0.2 cm |
